Alpha Plus POF Double Bubble Line
Alpha Plus POF Double Bubble Line
- LLDPE, EVA, PP, polyolefin copolymers
- Fully automatic line functionality, with intelligence controlled operational line speed
- Gauge variation and its correction is made both with flexible die lips and reheating oven
- Advanced winders with precised tension and taper tension control
- Cross-link Station can be integrated into the line
- Stand alone annealing station is available
Used for producing clear and thin shrink film for various applications like boxed chocolates, food packaging, stationary wrap, books, holiday paper rolls, etc
FEATURES:
Technical Specification (Typical)
|
Parameters |
DX-2000 |
DX-2500 |
|
Layflat Width (mm) |
max 2000 |
max 2500 |
|
Number of Layers using spiral Die |
3-7 |
3-7 |
|
Number of Layers with ADSSM |
up to 33 |
up to 33 |
|
Number of Extruders |
3-7 |
3-7 |
|
Thickness Range (microns) |
8-35 |
8-35 |
|
Output at 12 microns (Kg/hr) |
200-300 |
200-300 |
|
Mechanical Line Speed (m/min) |
100 |
100 |
|
Core Inner Diameter (mm) |
152 |
152 |
|
Roll Outer Diameter (mm) |
600 |
600 |
*SYSTEMS CAN BE CUSTOMIZED TO SPECIAL REQUIREMENTS
If you are interested to learn how Alpha Marathon's DOUBLE BUBBLE technology can improve your products and cost structure,, please contact us at (905)738-3682 or marketing@alphamarathon.com
