ALPHA ARTIFICIAL HORIZONTAL SAUSAGE CASING LINES "HS"
ALPHA HS is high-speed multilayer casing line belongs to a family of horizontal lines with multiple bubbles. The casing can be used for sausage and hot-dog skin casing. It can be either gas barrier casing or breathable for smoked sausages.
Typical Technology Process (Between Extrusion and Winding):
- Tube Forming (Vertical))
- Stretching (Horizontal)Stretching (Horizontal)
- Annealing (Horizontal)
- Cooling (Horizontal)
Typical Polymers:
- Nylon 6
- Nylon 666
- EVOH
- PVOH
- Polyethylene
- EVA
Technical Specifications
|
Parameters |
Skin Casing Lines |
Sausage Casing Lines |
|
Calibers, mm |
15-75 |
80-240 |
|
Number of Layers) |
1-3 |
5-9 |
|
Thickness Range, micron |
20-35 |
35-75 |
|
Extrusion Output, kg/h |
100 |
200-250 |
|
Net Output, kg/h |
25-50 |
80-150 |
|
Mechanical Line Speed, m/min |
400 |
200 |
|
Core ID, mm |
76 and 152 |
76 and 152 |
|
Roll OD, mm |
600 |
600 |
